CYLINDERS
GY6 125 A/C 2V
HMCS0501763WH
MATERIAL: ALUMINUM
MATERIAL: ALUMINUM
Specification
| MATERIAL | ALUMINUM | ENGINE STROKE | 4 STROKE |
|---|---|---|---|
| ORIGINAL SIZE | ø52.4 | ORIGINAL CC | 124CC |
| BIG BORE SIZE | ø63 | BIG BORE CC | 180CC |
| COUNTRY OF ORIGIN | TAIWAN |
Feature
ORIGINAL CYLINDER KIT - HMCS0501752.4
| ITEM | NO. |
| Aluminum cylinder ø52.4 | HMCY0501752.4 |
| Gaskets | HMGK0501752.4 |
| Cast piston | HMPS0501752.4 |
The piston assembly includes the piston pin, clips and piston rings.
BIG BORE CYLINDER KIT - HMCS0501763WH
| ITEM | NO. |
| Aluminum cylinder ø63 | HMCY0501763 |
| Cylinder head | HMCH0501763 |
| Gaskets | HMGK0501763 |
| Cast piston | HMPS0501763 |
The piston assembly includes the piston pin, clips and piston rings.
