CYLINDERS
MSX125 (4V)
HMCS03033
MATERIAL: ALUMINUM
MATERIAL: ALUMINUM
Specification
| MATERIAL | ALUMINUM | ENGINE STROKE | 4 STROKE |
|---|---|---|---|
| ORIGINAL SIZE | ø52.4 | ORIGINAL CC | 124.8CC |
| BIG BORE SIZE | ø59 | BIG BORE CC | 158.2CC |
| BIG BORE SIZE | ø63 | BIG BORE CC | 180CC |
| COUNTRY OF ORIGIN | TAIWAN |
Feature
ORIGINAL CYLINDER KIT - HMCS0303352.4
| ITEM | NO. |
| Aluminum cylinder ø52.4 | HMCY0303352.4 |
| Gaskets | HMGK0303352.4 |
| Cast piston | HMPS0303352.4 |
The piston assembly includes the piston pin, clips and piston rings.
BIG BORE CYLINDER KIT - HMCS0303359WH
| ITEM | NO. |
| Aluminum cylinder ø59 | HMCY0303359 |
| Cylinder head | HMCH0303359 |
| Gaskets | HMGK0303359 |
| Forged piston | HMPS0303359 |
The piston assembly includes the piston pin, clips and piston rings.
BIG BORE CYLINDER KIT - HMCS0303363WH
| ITEM | NO. |
| Aluminum cylinder ø63 | HMCY0303363 |
| Cylinder head | HMCH0303363 |
| Gaskets | HMGK0303363 |
| Forged piston | HMPS0303363 |
The piston assembly includes the piston pin, clips and piston rings.
