CYLINDERS
MAJESTY250
HMCS1102769
MATERIAL: ALUMINUM
MATERIAL: ALUMINUM
Specification
| MATERIAL | ALUMINUM | ENGINE STROKE | 4 STROKE |
|---|---|---|---|
| ORIGINAL SIZE | ø69 | ORIGINAL CC | 249CC |
| BIG BORE SIZE | ø74 | BIG BORE CC | 287CC |
| COUNTRY OF ORIGIN | TAIWAN |
Feature
ORIGINAL CYLINDER KIT - HMCS1102769
| ITEM | NO. |
| Aluminum cylinder ø69 | HMCY1102769 |
| Gaskets | HMGK1102769 |
| Cast piston | HMPS1102769 |
The piston assembly includes the piston pin, clips and piston rings.
BIG BORE CYLINDER KIT - HMCS1102774
| ITEM | NO. |
| Aluminum cylinder ø74 | HMCY1102774 |
| Gaskets | HMGK1102774 |
| Cast piston | HMPS1102774C |
| Forged piston | HMPS1102774F |
The piston assembly includes the piston pin, clips and piston rings.
